Camlock plug to plug stainless steel
The Camlock plug adapter made of AISI 316 (CF8M) stainless steel enables two Camlock plugs to be connected directly (plug to plug). Thanks to its robust design, this converter is corrosion-resistant, temperature-resistant, and suitable for numerous media. The full passage ensures minimal pressure loss, even when used with solids, as there are no internal valves.
materials
Body: AISI 316 (CF8M) stainless steel
Seal: NBR
Handle, ring: stainless steel
temperature range
-10 °C to +80 °C
benefits
Full passage without cross-sectional narrowing
Low pressure loss
Also suitable for solids, as there are no internal valves
High corrosion resistance thanks to AISI 316 stainless steel
Technical specifications
| Camlock size | Type | DN1 | DN2 | operating pressure | Material |
|---|---|---|---|---|---|
| 1" | A-A | DN25 | DN25 | 10 bar | SS316/CF8M |
| 2" | A-A | DN50 | DN50 | 10 bar | SS316/CF8M |
| 3" | A-A | DN80 | DN80 | 10 bar | SS316/CF8M |
