Technical data
| feature | Execution |
| connection | 2× external thread |
| Thread | BSPT (R) tapered, ISO 7/1 / DIN 2999 / BS 21, non-self-sealing |
| sealing | with hemp, PTFE tape, or sealing paste |
| Material | Stainless steel AISI 316 (V4A) / 1.4401 / X5CrNiMo17-12-2 |
| temperature range | -4 °F to 392 °F |
| Working pressure (PN) | 20 bar |
| Surface | Stainless steel gray, matte |
| Regulation | ISO 4144 |
| Properties | High corrosion and temperature resistance, food safe, resistant to chloride-containing media |
Variants
| Size | DN | Thread | Length (L) | Length (L1) | Wrench size (SW) |
| 1/8" | 5 | R 1/8" (9.73 mm) | 20 mm | 8 mm | 14 mm |
| 1/4" | 9 | R 1/4" (13.16 mm) | 25 mm | 9 mm | 15 mm |
| 3/8" | 13 | R 3/8" (16.66 mm) | 27 mm | 9 mm | 18 mm |
| 1/2" | 16.5 | R 1/2" (20.95 mm) | 34 mm | 13.5 mm | 22 mm |
| 3/4" | 21.5 | R 3/4" (26.44 mm) | 37 mm | 14 mm | 28 mm |
| 1" | 28 | R 1" (1.32 in) | 42 mm | 16 mm | 35 mm |
| 1 1/4" | 36 | R 1 1/4" (41.91 mm) | 48 mm | 19 mm | 43 mm |
| 1 1/2" | 41.5 | R 1 1/2" (47.81 mm) | 47.5 mm | 19 mm | 50 mm |
| 2" | 53 | R 2" (59.61 mm) | 57 mm | 22 mm | 61.5 mm |
2 ½" | |||||
3" | |||||
4" |
Advantages
Made from AISI 316 (V4A) stainless steel for maximum corrosion resistance
Pressure resistant up to 20 bar at 20 °C
Temperature resistant up to 200 °C
Suitable for water, steam, oils, chemicals, and many other media
Food safe and DVGW compliant
Ideal for use in industry, chemistry, food technology, and plant engineering
