2-arm beaker stirrer – 600 mm (for IBC)
The agitator is designed for fast stirring, homogenizing, and mixing directly in the IBC. The foldable agitator arms extend the diameter to 600 mm during operation and ensure efficient mixing with moderate drive power. Tool-free disassembly and the screw-free design in the product chamber facilitate cleaning and hygiene.
Technical specifications
| agitator type | total length | Diameter (folded) | Diameter (unfolded) | Max. speed | Material (product contact) | filling opening | Fixation | Weight | Special features |
|---|---|---|---|---|---|---|---|---|---|
| 2-arm beaker stirrer | 600 mm | 140 mm | 600 mm | 300 rpm | Stainless steel 1.4404 | DN 150 | Threaded pin M16 × 30 mm | 1.8 kg | Tool-free disassembly, no screws in the product compartment |
benefits
Compact installation thanks to 140 mm insertion diameter (DN 150)
Efficient mixing action thanks to 600 mm working diameter
Hygienic, screw-free design in the product chamber
Tool-free disassembly for quick cleaning
Robust stainless steel 1.4404 for high corrosion resistance
Note
Select maximum speed (300 rpm) and drive power according to media viscosity, density, and process requirements. Always check the material compatibility of the medium with stainless steel 1.4404 before use.
